PE900 Jaw Crusher Introduction
The PE900 Jaw Crusher delivers a powerful and precise primary crushing solution for medium-scale quarrying, mining, and aggregate processing. Combining a calibrated crushing force with a wide feed size range up to 500 mm, it efficiently processes materials such as granite, limestone, and recycled aggregates, delivering 80–180 t/h with consistent product quality and reliable performance.
| Quantity: | |
|---|---|
Product Overview: PE900 Medium-Capacity Jaw Crusher
The PE900 Jaw Crusher is engineered to balance power, precision, and operational flexibility in primary crushing applications. Featuring a 600 × 900 mm feed opening, adjustable discharge settings (130–200 mm), and a compact yet robust design, it is ideal for operations requiring efficient material reduction with easy installation and low operational noise.
Key Features of the PE900 Jaw Crusher
1. Adjustable Feeding & Discharge for Process Optimization
The crusher allows precise control over material flow and product size, with a quick-adjust discharge port that enables operators to tailor output to specific material characteristics without stopping production.
2. Calibrated Crushing Force for Efficient Size Reduction
Engineered to apply optimal crushing pressure, the PE900 reduces stones to desired sizes without over-crushing, improving product quality, reducing fines generation, and lowering energy consumption per ton.
3. Wide Feed Size Range with High Acceptance
Capable of handling feed sizes up to 500 mm, the crusher is versatile for both primary and secondary roles, processing everything from small stones to medium boulders with consistent efficiency.
4. Compact & Transport-Friendly Design
Weighing 17.8 tons with dimensions of 2248 × 2280 × 2373 mm, the PE900 is designed for easier transportation, installation, and relocation, making it suitable for fixed plants or mobile crushing setups.
5. Low-Noise, Low-Vibration Operation
Built with vibration-damping components and a dynamically balanced flywheel, the crusher operates with reduced noise and structural vibration, enhancing operator comfort and equipment longevity.
Applications of the PE900 Jaw Crusher
1. Granite & Hard Rock Quarry Primary Crushing
Efficiently processes hard and abrasive granite, basalt, and quartzite into primary crushed stone for construction and decorative aggregate production.
2. Limestone & Cement Raw Material Preparation
Crushes limestone, marl, and other cement feed materials to required sizes for kiln feed or further grinding in cement and lime plants.
3. Glass & Ceramic Raw Material Size Reduction
Handles recycled glass, feldspar, clay, and other ceramic precursors, providing controlled particle sizing for melting or forming processes.
4. Recycling of Construction & Demolition Waste
Processes concrete, bricks, and masonry into reusable aggregates, supporting sustainable building practices and circular economy initiatives.
| Model | PE900 |
| Feeding Date (W*L) | 600 * 900 |
| Discharge Wide in B | 130 - 200 |
| Max. Feeding Grain Size (mm) | 500 |
| Capacity (t/h) | 80 - 180 |
| Weight (t) | 17.8 |
| External Dimension (L * W * H) | 2248 * 2280 * 2373 |
| Motor Type | Y315M1-8 |
| Power (kw) | 75 |
| Rotate Speed (rotate / min) | 750 |
Performance Comparison: PE900 vs PE1600 Jaw Crusher
| Feature | PE900 | PE1600 |
|---|---|---|
| Feed Opening | 600 × 900 mm | 1300 × 1600 mm |
| Max. Feed Size | 500 mm | 1100 mm |
| Capacity | 80–180 t/h | 800–1300 t/h |
| Motor Power | 75 kW | 315–400 kW |
| Weight | 17.8 t | 110 t |
| Typical Use | Small to medium quarries, recycling | Large mining & infrastructure |
Why Choose the PE900 Jaw Crusher?
High Efficiency with Low Power Use: 75 kW motor supports 80–180 t/h throughput with low energy consumption per ton.
Quick & Safe Discharge Adjustment: Simple mechanical or hydraulic systems allow easy tuning of product size (130–200 mm).
Low Noise & Vibration Design: Engineered for smoother operation, reducing environmental impact and improving worksite comfort.
Heavy-Duty Yet Compact: Robust construction ensures durability while maintaining a transport-friendly size and weight.
Proven in Multiple Industries: Suitable for aggregates, mining, recycling, cement, and industrial minerals.
