PH-4 High-Efficiency Hydraulic Cone Crusher Introduction
Our Chuangli PH-4 High-Efficiency Hydraulic Cone Crusher delivers exceptional crushing performance, superior throughput, and precise product control in large-scale mining and aggregate operations. Powered by a robust 315 kW motor and featuring dual-chamber versatility (Superfine & Fine), this 26.5-ton crusher combines high productivity, energy efficiency, and advanced safety systems—making it the ideal solution for secondary, tertiary, and quaternary crushing in demanding industrial environments.
| Quantity: | |
|---|---|
Product Overview: PH-4 High-Capacity Hydraulic Cone Crusher
The PH-4 Hydraulic Cone Crusher is engineered for heavy-duty crushing of hard and abrasive materials, offering throughput capacities from 225–630 t/h with adjustable closed-side settings (16–51 mm). Its advanced hydraulic adjustment, durable construction, and intelligent automation ensure reliable operation, uniform product shape, and minimal downtime—supporting high-volume production in mining, construction, and recycling applications.
Key Features of the PH-4 Hydraulic Cone Crusher
1. High-Efficiency Crushing with Dual Chamber Flexibility
Equipped with interchangeable Superfine and Fine crushing chambers, allowing rapid adaptation to varying material types and product specifications—optimizing both reduction ratio and output quality.
2. Powerful 315 kW Motor for High Throughput & Energy Savings
Driven by a high-efficiency 315 kW motor (1490 rpm), the crusher delivers 225–630 t/h capacity with reduced energy consumption per ton, lowering operational costs while maintaining consistent, high-volume performance.
3. Precise Hydraulic Adjustment for Controlled Product Sizing
The hydraulic discharge setting system enables quick, accurate adjustment of the closed-side opening (16–51 mm range), ensuring uniform particle size distribution and flexibility to meet strict grading requirements.
4. Robust 26.5-Ton Construction with Enhanced Durability
Built with a heavy-duty frame, wear-resistant alloy components, and advanced liner profiles, the PH-4 withstands continuous operation in abrasive environments, extending service life and reducing part replacement frequency.
5. Intelligent Safety & Remote Control Capabilities
Incorporates hydraulic overload protection, automated cavity clearing, and remote monitoring systems to prevent damage, enhance operator safety, and enable off-site control—minimizing onsite risks and unplanned downtime.
6. High Reduction Ratio & Superior Product Shape
Designed to achieve a reduction ratio of up to 6:1, producing well-shaped, cubical aggregates ideal for high-quality concrete, asphalt, and construction applications.
Applications of the PH-4 Hydraulic Cone Crusher
1. Large-Scale Mining & Mineral Processing
Ideal for reducing hard and abrasive ores such as iron, copper, and gold in secondary to quaternary crushing stages, preparing material for grinding, leaching, or further beneficiation.
2. High-Volume Aggregate Production for Major Infrastructure
Produces uniformly graded, cubical aggregates for concrete, asphalt, road base, and railway ballast in large construction and infrastructure projects.
3. Recycling of C&D Waste & Industrial By-Products
Processes concrete, demolition debris, slag, and industrial minerals into high-value recycled aggregates, supporting sustainable construction and circular economy initiatives.
4. Cement, Silicate & Chemical Raw Material Preparation
Crushes limestone, clinker, quartz, feldspar, and other raw materials for cement, glass, ceramic, and chemical production, offering consistent sizing and low contamination.
>> Specifications
| Model | Motor Power (kw) / Related Speed | Weight (t) | Chamber = Type | Discharge Gate A | Close Side Feed Openning B |
| PH-4 | 315kw ~ 1490r / min | 26.5 | Superfine | 25 ~ 55 | 111 |
| Fine | 30 ~ 60 | 250 |
>> Capacity t/h
| Model | Closed side discharge gate | ||||||||
| Ton (Hour) | 16 mm | 19 mm | 22 mm | 25 mm | 32 mm | 38 mm | 45 mm | 51 mm | |
| PH-4 | t / h | 225 - 280 | 255 - 320 | 275 - 345 | 295 - 370 | 325 - 430 | 360 - 490 | 410 - 560 | 465 - 630 |
PH-4 vs CM1000 Cone Crusher
| Feature | PH-4 Hydraulic Cone | CM1000 Cone Crusher |
|---|---|---|
| Power | 315 kW | 710 kW |
| Max Feed Size | ~250 mm (Fine chamber) | ~620 mm |
| Throughput | Up to 630 t/h | 1500–2500 t/h |
| Application Stage | Secondary/tertiary/quaternary | High-capacity secondary/tertiary |
| Design Focus | Precision shaping, versatility | Ultra-high throughput, automation |
Why Choose the PH-4 High-Efficiency Hydraulic Cone Crusher?
High Throughput with Low Energy Use: 315 kW motor delivers up to 630 t/h with optimized power consumption.
Quick Chamber & Setting Changes: Hydraulic adjustment and interchangeable liners reduce downtime and increase plant flexibility.
Superior Product Shape: Engineered for high reduction ratios and cubical output, improving aggregate quality and marketability.
Built for Tough Conditions: Robust 26.5-ton construction ensures reliability in abrasive, high-load environments.
Smart & Safe Operation: Integrated
