PE1500 Jaw Crusher Introduction
Our PE1500 Jaw Crusher is engineered with advanced automation and intelligent control features, enabling remote operation, real-time monitoring, and predictive diagnostics for enhanced safety and efficiency. Equipped with a self-lubricating system, energy-saving design, and a high-capacity 800–1000 t/h throughput, it delivers reliable, low-maintenance performance in large-scale infrastructure, mining, recycling, and industrial waste processing applications.
| Quantity: | |
|---|---|
Product Overview: PE1500 High-Capacity Automated Jaw Crusher
The PE1500 Jaw Crusher represents the forefront of primary crushing technology, integrating smart control systems, remote operational capability, and heavy-duty mechanical design. With a large 1200×1500 mm feed opening and optimized kinematics, it achieves high reduction ratios, increased output, and lower operational costs, making it ideal for demanding large-scale projects and continuous industrial use.
Key Features of the PE1500 Jaw Crusher
1. Advanced Automation with Remote Control & Monitoring
Operators can remotely control and adjust crushing parameters from a safe distance via an intuitive interface. The integrated intelligent system provides real-time performance monitoring, fault diagnosis, and early alerts to prevent unplanned downtime and ensure operational stability.
2. High-Efficiency Crushing with Increased Output
The optimized large crushing stroke and enhanced kinematics improve work efficiency, increasing output by up to 20% compared to conventional designs, while maintaining consistent product size and shape.
3. Self-Lubricating System for Reduced Maintenance
An automated centralized grease lubrication system ensures continuous, precise lubrication of all critical moving parts, reducing manual intervention, extending component life, and minimizing maintenance frequency.
4. Heavy-Duty Design with Quick Discharge Adjustment
Built with reinforced frame, large-diameter eccentric shaft, and durable jaw plates, the crusher withstands extreme loads. The hydraulic or mechanical adjustment system allows quick and safe setting of the discharge opening (250–350 mm) without stopping operation.
5. Energy-Saving Operation with Low Noise & Vibration
The crusher’s optimized dynamics and balanced moving mass reduce vibration and noise levels, while the efficient drive system (250–315 kW motor) lowers specific energy consumption per ton of material processed.
Applications of the PE1500 Jaw Crusher
1. Large-Scale Infrastructure & Construction Projects
Primary crushing of blasted rock for highways, railways, dams, and airport runways, supplying high-volume, specification aggregate for foundations and structural fill.
2. Mining & Mineral Exploration Sample Processing
Rapid reduction of bulk ore samples during exploration and feasibility studies, enabling efficient analysis of mineral content and grade.
3. Recycling & Scrap Processing Facilities
Crushing demolition concrete, scrap metal, construction waste, and electronic components to recover valuable materials and reduce landfill volume.
4. Industrial & Hazardous Waste Size Reduction
Processing large industrial waste, slag, and by-products into manageable sizes for safe disposal, recycling, or further treatment.
5. Quarry & Aggregate Primary Crushing Stations
Serving as the primary crusher in fixed or semi-mobile crushing plants, delivering consistent feed to secondary and tertiary crushing circuits.
| Model | PE1500 |
| Feeding Date (W*L) | 1200 * 1500 |
| Discharge Wide in B | 250 - 350 |
| Max. Feeding Grain Size (mm) | 1000 |
| Capacity (t/h) | 800 - 1000 |
| Weight (t) | 90 |
| External Dimension (L * W * H) | 3900 * 3410 * 4088 |
| Motor Type | YR-355M4-6 |
| Power (kw) | 250 - 315 |
| Rotate Speed (rotate / min) | 990 |
PE1500 vs Gyratory Crusher (Primary Crushing)
| Feature | PE1500 Jaw Crusher | Gyratory Crusher |
|---|---|---|
| Feed Size | Up to 1000 mm | Often larger (>1300 mm) |
| Capacity Range | 800–1000 t/h | Typically higher (1500–4500 t/h) |
| Footprint & Height | Lower profile, easier installation | Taller, larger foundation required |
| Product Shape | Slightly more elongated | More uniform, slab-like |
| Automation Readiness | High, with integrated smart features | Often requires additional retrofitting |
Why Choose the PE1500 Jaw Crusher?
Smart & Safe Operation: Remote control and real-time diagnostics enhance safety and uptime.
High Throughput with Efficiency: 800–1000 t/h capacity with up to 20% higher output efficiency.
Low Maintenance & Automated Lubrication: Self-lubricating system reduces manual tasks and extends component life.
Robust & Durable Construction: Heavy-duty design ensures reliability under continuous high-load conditions.
Energy & Environmentally Optimized: Lower power consumption, reduced noise, and vibration support sustainable operations.
