PH-5 High-Efficiency Hydraulic Cone Crusher Introduction
Our Chuangli PH-5 High-Efficiency Hydraulic Cone Crusher is engineered for heavy-duty, high-capacity crushing in the most demanding mining, quarrying, and industrial applications. Powered by a robust 400 kW motor and designed with dual-chamber versatility (Superfine & Fine), this 36.5-ton crusher delivers exceptional throughput (280–790 t/h), precise product control, and reliable, low-maintenance operation—making it the ultimate solution for large-scale secondary, tertiary, and quaternary crushing.
| Quantity: | |
|---|---|
Product Overview: PH-5 Ultra-High-Capacity Hydraulic Cone Crusher
The PH-5 Hydraulic Cone Crusher represents the pinnacle of crushing performance, combining advanced hydraulic technology, durable construction, and intelligent automation to handle the hardest and most abrasive materials. With adjustable closed-side settings (16–51 mm) and throughput up to 790 t/h, it ensures maximum productivity, uniform product shape, and operational safety in large and medium-sized mineral processing and aggregate plants.
Key Features of the PH-5 Hydraulic Cone Crusher
1. Ultra-High Crushing Efficiency with Dual Chamber Versatility
Equipped with interchangeable Superfine and Fine crushing chambers, enabling rapid adaptation to varying material hardness and product requirements—optimizing both reduction ratio and output quality for high Work Index and Abrasion Index materials.
2. Powerful 400 kW Motor for Maximum Throughput & Energy Savings
Driven by a high-efficiency 400 kW motor (1490 rpm), the crusher delivers 280–790 t/h capacity with industry-leading energy efficiency, significantly lowering operational costs while maintaining consistent, high-volume performance.
3. Precise Hydraulic Adjustment for Controlled Product Sizing
The advanced hydraulic discharge setting system allows quick, accurate adjustment of the closed-side opening (16–51 mm range) without disassembly, ensuring uniform particle size distribution and flexibility to meet strict grading specifications.
4. Robust 36.5-Ton Construction with Enhanced Durability
Built with a heavy-duty frame, wear-resistant alloy components, and advanced liner profiles, the PH-5 withstands continuous operation in the most abrasive environments, extending service life and reducing part replacement frequency.
5. Intelligent Safety & Remote Control Capabilities
Incorporates hydraulic overload protection, automated cavity clearing, and remote monitoring systems to prevent damage, enhance operator safety, and enable off-site control—minimizing onsite risks and unplanned downtime.
6. High Reduction Ratio & Superior Cubical Product Shape
Engineered to achieve a reduction ratio of up to 6:1, producing well-shaped, cubical aggregates ideal for high-quality concrete, asphalt, and construction applications.
Applications of the PH-5 Hydraulic Cone Crusher
1. Large-Scale Mining & Mineral Processing
Ideal for reducing hard and abrasive ores such as iron, copper, and gold in secondary to quaternary crushing stages, preparing material for grinding, leaching, or further beneficiation.
2. High-Volume Aggregate Production for Major Infrastructure
Produces uniformly graded, cubical aggregates for concrete, asphalt, road base, and railway ballast in large construction and infrastructure projects.
3. Recycling of C&D Waste & Industrial By-Products
Processes concrete, demolition debris, slag, and industrial minerals into high-value recycled aggregates, supporting sustainable construction and circular economy initiatives.
4. Cement, Silicate & Chemical Raw Material Preparation
Crushes limestone, clinker, quartz, feldspar, and other raw materials for cement, glass, ceramic, and chemical production, offering consistent sizing and low contamination.
5. Sandstone Making & Fine Crushing Operations
Used in large and medium-sized mineral dressing plants for fine crushing operations, producing high-quality sand and fine aggregates for various industrial applications.
>> Specifications
| Model | Motor Power (kw) / Related Speed | Weight (t) | Chamber = Type | Discharge Gate A | Close Side Feed Openning B |
| PH-5 | 400kw ~ 1490r / min | 36.5 | Superfine | 25 ~ 60 | 133 |
| Fine | 40 ~ 70 | 280 |
>> Capacity t/h
| Model | Closed side discharge gate | ||||||||
| Ton (Hour) | 16 mm | 19 mm | 22 mm | 25 mm | 32 mm | 38 mm | 45 mm | 51 mm | |
| PH-5 | t / h | 280 - 350 | 320 - 400 | 345 - 455 | 365 - 455 | 405 - 535 | 445 - 605 | 510 - 700 | 580 - 790 |
PH-5 vs Gyratory Crusher (Secondary/Tertiary Stage)
| Feature | PH-5 Hydraulic Cone | Gyratory Crusher (e.g., CLX5587) |
|---|---|---|
| Power | 400 kW | 710 kW |
| Max Feed Size | ~280 mm | ~1200 mm |
| Throughput | Up to 790 t/h | 2500–3500 t/h |
| Product Shape | More uniform, cubical | Coarser, less shaped |
| Application Focus | Precision shaping, high-quality aggregate | Ultra-high-capacity primary crushing |
Why Choose the PH-5 High-Efficiency Hydraulic Cone Crusher?
Ultra-High Throughput with Low Energy Use: 400 kW motor delivers up to 790 t/h with optimized power consumption.
Quick Chamber & Setting Changes: Hydraulic adjustment and interchangeable liners reduce downtime and increase plant flexibility.
Superior Product Shape: Engineered for high reduction ratios and cubical output, improving aggregate quality and marketability.
Built for Tough Conditions: Robust 36.5-ton construction ensures reliability in abrasive, high-load environments.
Smart & Safe Operation: Integrated automation and protection systems enhance safety and operational control.
