PH-1 Compact Hydraulic Cone Crusher Introduction
The Chuangli PH-1 Compact Hydraulic Cone Crusher is engineered to deliver high-performance secondary and tertiary crushing in a versatile, space-efficient package. With five interchangeable crushing cavities (C1 Extra Coarse to F2 Extra Fine) and a fully hydraulic adjustment system, it ensures precise product sizing, energy-efficient operation, and reliable performance for aggregates, mining, recycling, and industrial applications.
7T Efficient Hydraulic Cone Crusher | PH-1
CHUANGLII
| Quantity: | |
|---|---|
Product Overview: PH-1 Multi-Cavity Hydraulic Cone Crusher
The PH-1 Hydraulic Cone Crusher combines advanced crushing technology with intelligent automation in a compact 90 kW design. Featuring a hydraulic CSS adjustment, inter-particle crushing optimization, and real-time monitoring, it provides operators with exceptional control over product gradation, operational safety, and total cost of ownership—making it ideal for modular plants and mobile setups.
Key Features of the PH-1 Hydraulic Cone Crusher
1. Multi-Cavity Design for Maximum Application Flexibility
Offers five cavity configurations (C1 to F2), enabling seamless switching between coarse, medium, and fine crushing to meet varying material and output specifications without machine modification.
2. Fully Hydraulic Closed-Side Setting Adjustment
CSS is quickly and precisely adjusted via hydraulic motor, allowing changes from 6 to 51 mm in real time without manual intervention, minimizing downtime and ensuring consistent product quality.
3. Energy-Efficient 90 kW Drive System
Designed with an optimized hydraulic circuit and efficient motor to deliver 45–140 t/h throughput with minimal power consumption, reducing operational costs and supporting sustainable production.
4. Intelligent Automation & Remote Monitoring
Equipped with integrated sensors and IoT-ready controls that monitor performance, prevent overloads, and enable remote operation, enhancing safety, efficiency, and predictive maintenance capabilities.
5. Robust Construction with Extended Service Life
Built with high-strength alloy components, manganese steel liners, and sealed lubrication systems to withstand abrasive materials and extend wear-part longevity in demanding environments.
6. Compact Footprint for Space-Constrained Installations
With overall dimensions of 1705×1510×1583 mm, the PH-1 fits easily into modular plants, mobile crushing units, or sites with limited space, offering high productivity in a small footprint.
Model | Cavity | Feeding Opening (mm) | Minimum Discharge Opening (mm) | Capacity (t/h) | Nominal Installed Power (kw) | Max. Installed Power (kw) | Overall Dimension (mm) |
PH-1 | C1 Extra Coarse | 140 | 19 | 75~140 | 90 | 90 | 1705x1510x1583 |
C2 Coarse | 100 | 13 | 60~110 | 90 | 90 | 1705x1510x1583 | |
M Medium | 70 | 9 | 52~100 | 90 | 90 | 1705x1510x1583 | |
F1 Fine | 50 | 9 | 50~95 | 90 | 90 | 1705x1510x1583 | |
F2 Extra Fine | 20 | 6 | 45~90 | 90 | 90 | 1705x1510x1583 |
Indicative Capacities
Model | Closed Side Settings | ||||||||||
/ | 8 | 10 | 13 | 16 | 19 | 22 | 25 | 32 | 38 | 44 | 51 |
PH-1 | 50~60 | 55~70 | 60~80 | 70~90 | 75~95 | 80~100 | 85~110 | 95~140 | |||
Capacity is indicative for instantaneous sampling results of materials with bulk density of 1.6t/m3
PH-1 vs Small Impact Crusher (Secondary Crushing)
| Feature | PH-1 Cone Crusher | Small Impact Crusher (e.g., PFQ1315) |
|---|---|---|
| Product Shape | More cubical, uniform | Can be more angular, less consistent |
| Wear in Abrasive Material | Lower (compression crushing) | Higher (impact wear) |
| Noise & Dust | Generally lower | Typically higher |
| Best For | Aggregate shaping, fines production | Recycling, medium-hard rock |
Applications of the PH-1 Hydraulic Cone Crusher
1. Aggregate & Manufactured Sand Production
Ideal for producing high-quality, well-graded aggregates and sand for concrete, asphalt, and construction fill, with excellent particle shape and minimal flakiness.
2. Mining & Mineral Secondary/Tertiary Reduction
Used to crush medium-hard ores such as limestone, iron, and copper after primary crushing, providing controlled feed for grinding or leaching processes.
3. Recycling of Construction & Demolition Materials
Processes recycled concrete, bricks, and asphalt into specification aggregates for sustainable building and civil engineering projects.
4. Industrial Raw Material Preparation
Crushes clinker, gypsum, industrial minerals, and specialty aggregates for cement, ceramics, glass, and chemical production.
5. Mobile & Modular Crushing Plants
Suited for portable setups in urban construction, temporary job sites, and remote locations due to its compact design, energy efficiency, and quick setup.
6. Railway Ballast & Road Base Production
Delivers precisely graded, angular aggregates for railway track beds and road foundation layers, meeting strict geometric and durability requirements.
Why Choose the PH-1 Hydraulic Cone Crusher?
Versatile Multi-Cavity Design: Five cavity options adapt to diverse materials and product needs.
Precise Hydraulic Control: Real-time CSS adjustment ensures consistent output and quick changeovers.
Compact & Energy-Efficient: Small footprint and 90 kW motor maximize output per space and power.
Smart & Connected Operation: IoT-enabled monitoring supports predictive maintenance and remote management.
Built to Last: Robust construction and sealed lubrication extend service life in harsh conditions.
Indicative Gradation Curves
Gradation and capacities shown are closely related to crushing chamber, feeding size, material crushability, clay and moisture content, and more.
