PH-8 High-Capacity Hydraulic Cone Crusher Introduction
Our Chuangli PH-8 High-Capacity Hydraulic Cone Crusher is engineered for high-performance secondary, tertiary, and quaternary crushing in large-scale mining, quarrying, and industrial operations. Powered by a powerful 630 kW motor (980 rpm) and featuring a heavy-duty 66-ton design, it delivers exceptional throughput of 385–1200 t/h with superior product shape, operational safety, and energy-efficient performance—making it the ideal solution for processing hard and abrasive materials like granite, basalt, and quartzite.
| Quantity: | |
|---|---|
Product Overview: PH-8 Heavy-Duty Hydraulic Cone Crusher
The PH-8 Hydraulic Cone Crusher is built for continuous high-volume crushing under the most demanding conditions. With dual-chamber configurations (Superfine & Fine), adjustable closed-side settings (16–51 mm), and advanced hydraulic control, it ensures reliable operation, minimal downtime, and consistent product quality across mining, aggregates, recycling, and industrial mineral processing.
Key Features of the PH-8 Hydraulic Cone Crusher
1. High-Performance Crushing with Dual Chamber Flexibility
Equipped with interchangeable Superfine and Fine crushing chambers, enabling operators to adapt quickly to varying material types and product requirements—optimizing both throughput and final product specifications.
2. Powerful 630 kW Low-Speed Motor for High Torque & Efficiency
Driven by a 630 kW motor operating at 980 rpm, the crusher provides high torque output and smooth operation, delivering 385–1200 t/h capacity with reduced energy consumption and enhanced mechanical reliability.
3. Advanced Hydraulic Adjustment for Precise Product Control
The fully hydraulic adjustment system allows for quick and accurate changes to the closed-side setting (16–51 mm) without manual intervention, ensuring consistent particle size distribution and operational flexibility.
4. Robust 66-Ton Construction for Long-Term Durability
Constructed with a reinforced heavy-duty frame, premium alloy components, and wear-resistant liners, the PH-8 is designed to withstand continuous high-impact crushing in abrasive environments, extending service life and minimizing maintenance.
5. Integrated Safety & Automated Protection Systems
Features automatic overload protection, hydraulic cavity clearing, and remote monitoring capabilities to safeguard equipment, enhance operator safety, and prevent unplanned stoppages.
6. Energy-Efficient Operation with Low Maintenance Requirements
Designed with optimized hydraulic circuits and efficient drive systems to reduce power consumption, while its modular design and accessible components simplify maintenance and reduce service time.
>> Specifications
| Model | Motor Power (kw) / Related Speed | Weight (t) | Chamber = Type | Discharge Gate A | Close Side Feed Openning B |
| PH-8 | 630kw ~ 980r / min | 66 | Superfine | 30 ~ 65 | 219 |
| Fine | 40 ~ 70 | 350 |
>> Capacity t/h
| Model | Closed side discharge gate | ||||||||
| Ton (Hour) | 16 mm | 19 mm | 22 mm | 25 mm | 32 mm | 38 mm | 45 mm | 51 mm | |
| PH-8 | t / h | 385 - 500 | 435 - 545 | 470 - 600 | 495 - 730 | 545 - 800 | 600 - 950 | 690 - 1050 | 785 - 1200 |
PH-8 vs CM1000 Cone Crusher (Secondary/Tertiary Stage)
| Feature | PH-8 Hydraulic Cone | CM1000 Cone Crusher |
|---|---|---|
| Power | 630 kW | 710 kW |
| Weight | 66 t | 110 t |
| Max Capacity | 1200 t/h | 2500 t/h |
| Speed | 980 rpm | Higher speed design |
| Application Focus | Precision shaping, hard rock processing | Ultra-high throughput, large feed size |
Applications of the PH-8 Hydraulic Cone Crusher
1. Large-Scale Mining & Mineral Processing
Ideal for secondary and tertiary crushing of hard and abrasive ores such as granite, basalt, iron ore, and copper ore, preparing material for further grinding and beneficiation.
2. High-Volume Aggregate Production for Major Infrastructure
Produces high-quality, cubical aggregates for concrete, asphalt, road base, and railway projects, meeting strict grading and shape requirements.
3. Recycling of Concrete, Asphalt & Demolition Materials
Processes C&D waste into specification-grade recycled aggregates, supporting sustainable construction practices and reducing landfill reliance.
4. Industrial Mineral & Cement Raw Material Crushing
Handles materials such as limestone, clinker, slag, silica sand, and cement clinker for use in cement, glass, ceramics, and chemical production.
5. Quarrying & Sandstone Production
Used in large quarry operations to produce crushed stone, sand, and gravel for construction and industrial applications.
Why Choose the PH-8 High-Capacity Hydraulic Cone Crusher?
High Throughput with Energy Efficiency: 630 kW low-speed motor delivers up to 1200 t/h with optimized power use.
Quick Adjustment & Easy Maintenance: Fully hydraulic setting changes and modular design reduce downtime and service complexity.
Superior Product Shape & Consistency: Engineered for uniform, cubical output suitable for high-value applications.
Built for Extreme Conditions: Heavy-duty 66-ton construction ensures long-term reliability in abrasive, high-impact environments.
Smart & Safe Operation: Integrated protection and remote monitoring enhance safety and operational control.
