CM1000 Cone Crusher Introduction
Our CM1000 Cone Crusher is engineered for ultra-high-capacity secondary and tertiary crushing, delivering exceptional throughput and efficiency in demanding large-scale operations. Designed with user-friendly operation, robust construction, and advanced hydraulic automation, it simplifies installation and operation while ensuring reliable performance even under the most challenging working conditions.
| Quantity: | |
|---|---|
Product Description: CM1000 High-Performance Single-Cylinder Cone Crusher
The CM1000 Cone Crusher combines powerful crushing capability with intelligent hydraulic control to achieve high production efficiency and large crushing ratios. Featuring a 620 mm feeding gate and a high-output capacity of 1500–2500 t/h, it is designed to reduce large stones to specification-sized aggregates in a single pass, minimizing the need for additional crushing stages and lowering overall plant complexity.
Key Features of the CM1000 Cone Crusher
1. High Production Efficiency with Large Crushing Ratio
The optimized crushing chamber and high rotational inertia enable a large crushing ratio, effectively reducing feed size from 620 mm to desired product dimensions in one pass, supporting high-volume production with fewer processing stages.
2. User-Friendly Operation with Hydraulic Automation
Equipped with an intuitive control system and fully hydraulic adjustment, protection, and cavity cleaning functions, the CM1000 simplifies operation, enhances safety, and reduces manual intervention for higher productivity.
3. Efficient Feeding & Material Distribution System
The engineered feeding mechanism ensures smooth, continuous material flow into the crushing chamber, promoting even wear and maximizing throughput efficiency across varying feed conditions.
4. Durable Construction with Extended Service Life
Built with high-strength alloy steel and precision manufacturing, the crusher is designed for long-term reliability in abrasive and high-load environments, delivering a strong return on investment through reduced downtime and maintenance.
5. Low Operating Costs with Minimal Wear Consumption
Utilizing advanced thin-oil lubrication and wear-resistant liners, the CM1000 reduces friction and component wear, resulting in lower spare parts consumption and reduced operating expenses per ton crushed.
Applications of the CM1000 Cone Crusher
1. Large-Scale Quarry & Aggregate Production
Ideal for high-volume crushed stone and sand operations, supplying consistent, high-quality aggregates for major infrastructure, commercial construction, and ready-mix concrete production.
2. Cement & Industrial Raw Material Processing
Used for crushing limestone, clinker, and other cement raw materials into uniform sizes, supporting efficient kiln feed preparation and plant throughput optimization.
3. Mining & Metallurgical Ore Reduction
Capable of handling copper, iron, gold, and other ores in secondary and tertiary stages, preparing material for further grinding and beneficiation with high efficiency and reliability.
4. Mega Construction & Infrastructure Projects
Supplies large volumes of specification aggregates for dams, highways, ports, and rail projects where continuous, high-tonnage output is critical to project timelines.
CM1000 Technical Specifications：
| Model | Size of feeding gate (mm) | Capacity (t/h) | Power (kw) | Weight (t) |
| CM1000 | 620 | 1500 - 2500 | 710 | 110 |
Performance Comparison: CM1000 vs CM800 & CM500
| Feature | CM1000 Cone Crusher | CM800 Cone Crusher | CM500 Cone Crusher |
|---|---|---|---|
| Feed Opening | 620 mm | 530 mm | 500 mm |
| Capacity | 1500–2500 t/h | 1000–1500 t/h | 700–1000 t/h |
| Power | 710 kW | 500 kW | 400 kW |
| Weight | 110 t | 70 t | 41 t |
| Key Strength | Ultra-high capacity, automation, low wear cost | High throughput, robust design | Optimized chamber, vibration control |
| Ideal For | Mega quarries, mining, large cement plants | Large aggregate and mining operations | Medium-scale aggregates, recycling |
CM1000 vs Gyratory Crusher (Primary Crushing Comparison)
| Feature | CM1000 Cone Crusher | Gyratory Crusher |
|---|---|---|
| Stage | Secondary/Tertiary | Primary |
| Feed Size | Up to 620 mm | Typically >1000 mm |
| Product Shape | More uniform, better cubicity | Coarser, less shaped output |
| Automation Level | High, with hydraulic controls | Often lower, more mechanical |
| Flexibility | Easier to relocate, adapt in circuit | Fixed, high-capacity installation |
Why Choose the CM1000 Cone Crusher?
Ultra-High Throughput: Delivers 1500–2500 t/h, making it one of the highest-capacity cone crushers in its class.
Advanced Hydraulic Automation: Simplifies operation, enhances safety, and supports remote monitoring and control.
Low Wear & Operating Costs: Thin-oil lubrication and durable liners reduce maintenance frequency and spare parts consumption.
Flexible Cavity Options: Multiple crushing chamber configurations available to match different material types and product requirements.
Proven in Heavy-Duty Applications: Engineered for reliability in mining, quarrying, and industrial mineral processing.
